post #41 of 330 (permalink) Old 12-28-2005, 05:26 PM
ASSSSS-HOOOOOLE

Oldyeller's Avatar

Join Date: Aug 2005
Location: AZ
Posts: 2,442
Bronco Info: Broncos Are Gay.
iTrader: (0)
Quote:
Originally Posted by dach
My stock FSB 351w is 31" with 3.08

I want to go 35" with 3.54

They are the same ratio but is it enough for the 35" or is it better going to 3.73??


Why in USA a lot of people go 4.11 / 4.56 ??

The 4.11/4.56 gearings allow for your motor to turn the 35" tires just as easily as if the bronco was driving on the stock tires. If you try and put on 35" tires with 3.54 gears you are going to get poor gas mileage and it will be much harder on the engine getting the vehicle up to speed. You will also not have any low end "grunt" when trying to crawl up rocks or steep hills, or even just getting up to speed on the highway.

Good Luck
And welcome to FSB, I don't think we have many members from Belgium

Old Yeller

Quote:
Originally Posted by 4x4bronco925 View Post
Oldyeller seems to be in-human. He never makes mistakes and is always right. Enough said.

Quote:
Originally Posted by 302 & 3-inline6's
my rear is getting real sloppy
Oldyeller is offline
Sponsored Links
Advertisement

post #42 of 330 (permalink) Old 12-28-2005, 05:43 PM
Registered User

Chuck's Avatar

Join Date: Feb 2005
Location: Smithfield, VA
Posts: 1,213
Bronco Info: 91 302/E4OD/3.55, F-150 cab
iTrader: (0)
First off, a very handy tool one of the other guys here linked up the other day ... excellent rpm calculator for various gears, transmissions, tires, and transfer case combinations. It's the quickest and cleanest tool I've seen yet for checking engine speed for different conditions, plus the owner of the site has been very quick to add different transmissions on request.

Second -- usually your primary concern with gearing is getting your operating RPM where you want it to be at your usual cruise speed. This has a huge effect on both economy and acceleration. Most of the engines used in the Bronco will get best economy if they're turning around 1700-2000RPM at cruise, from what I've seen. Too low and you fall out of the powerband (and efficiency band) of the engine, and too high you lose too much to friction losses at cruise.

With your current gearing, 31's, and non-OD tranny, you're right about there with your current combo -- about 2000rpm at 60mph. Keep in mind, though, that a lot of the guys with slightly later trucks have an overdrive tranny, and get about the same operating RPM with 4.10's and overdrive, on the same tires.

Unfamiliar the miles under my heels ...
Structural Engineer / General Steel Geek
A Turn Of The Nut -- Pickwick Fields Lamb -- 87/91 F-150 cab swap -- My Supermotors
Chuck is offline
post #43 of 330 (permalink) Old 12-29-2005, 04:18 AM
Registered User

dach's Avatar

Join Date: Nov 2005
Location: Belgium
Posts: 42
Bronco Info: 1988 XLT 351W
iTrader: (0)
hem...
my axle code is 18 = 3.08
at cruise 65 mph = 2300 rpm.

It's C6 but non AOD. Chuck is maybe right with his explanations about AOD. In Belgium everybody cruise at 75 mph.

3.55 will fit good due to the same ratio or I put 3.73 due to the extra weight of wheels and tyres??


I think I'm the only one from Belgium. Because we are plenty of beer in Belgium.
dach is offline

post #44 of 330 (permalink) Old 12-29-2005, 08:35 AM
ASSSSS-HOOOOOLE

Oldyeller's Avatar

Join Date: Aug 2005
Location: AZ
Posts: 2,442
Bronco Info: Broncos Are Gay.
iTrader: (0)
Stella Artois is a Belgian beer right?

There are a lot of breweries in Belgium for sure,
I would personally go with the 3.73's out of your two choices, but then again, if it were me I would go with the 4.11's. But that's because I use my rig primarily for towing and the trail. I don't cruise the highway in it daily so I didn't build it based on what Rpm's i'd run on the highway. What it comes down to is what you use your bronco for the most. Do you go offroad alot, or do you use it mostly for driving 75 on the highway?

Quote:
Originally Posted by 4x4bronco925 View Post
Oldyeller seems to be in-human. He never makes mistakes and is always right. Enough said.

Quote:
Originally Posted by 302 & 3-inline6's
my rear is getting real sloppy
Oldyeller is offline
post #45 of 330 (permalink) Old 12-29-2005, 09:14 AM
Registered User

dach's Avatar

Join Date: Nov 2005
Location: Belgium
Posts: 42
Bronco Info: 1988 XLT 351W
iTrader: (0)
The most popular beer in Belgium is Jupiler. But we have a lot of special beer, 400 and more..

I use on highway and offroad.
I want to keep the same rpm.
The engine 351W is torky engine isn't?
dach is offline
post #46 of 330 (permalink) Old 12-29-2005, 01:10 PM
Registered User

dach's Avatar

Join Date: Nov 2005
Location: Belgium
Posts: 42
Bronco Info: 1988 XLT 351W
iTrader: (0)
What do you prefer for your ring?

http://store.summitracing.com/defaul...=egnsearch.asp

Tell me what's the best quality but not too much for my FSB 35'...
dach is offline
post #47 of 330 (permalink) Old 02-09-2006, 07:36 PM
Registered User

Seabronc's Avatar

Join Date: Aug 2005
Location: North of NYC
Posts: 612
Bronco Info: 1983 FSB, 351W, Holley 4BBL, 31x10.5, Ford 8.8 3.08:1 rear
iTrader: (1)
Try this chart from Jefff's Broco Graveyard catalog. http://www.supermotors.org/getfile/2...e/100_3392.jpg

Fred


1983 FSB
351W
Holley 4 BBL 4160
MSD6AL & Blaster 2
Wipers ON / Head Lights ON Control
Head Light wiring upgrade
1996 Lincoln Mark VIII 4200 CFM Electric Fan
1996 Lincoln Mark VIII 3G 130 Amp Alternator
31x10.5x15
Ford 8.8 3.08:1 rear
Dana 44 3.08:1 front


Supermotors http://www.supermotors.net/212

Communication: I know you think you know what I said, but what you need to know is, I didn't say what I meant.

BRONCO's IS MPVs NOT SUVs
Seabronc is offline
post #48 of 330 (permalink) Old 02-12-2006, 08:54 PM
Registered User

dogonmut's Avatar

Join Date: Mar 2003
Location: On your mom.
Posts: 3,645
iTrader: (8)
I thought I'd add a little real world info.

I installed 5.38:1 gears yesterday. I took a quick 2 mile run down the hiway moments ago to see what my rpm's would be like at 65 mph(mph measured with a GPS unit). Here's what I got:

Trandmission - e4od
Axle - Sterling 10.25
Gears - 5.38:1 Yukon
Tires - 38.5 x 14.50 x 16.5 TLS SX
Actual tire height - 36.5" (tires at 1/2 tread or so)
PSI - 25
Speed - 65 MPH
RPM's - 2400
Bling factor - can "cherp" the tires from a stop
Estimated milage - 6MPG city or hiway/3 gallons per mile in 4 low
dogonmut is offline
post #49 of 330 (permalink) Old 03-15-2006, 11:35 PM
Registered User

Dave88LX's Avatar

Join Date: Oct 2004
Location: Red Lion, PA (York)
Posts: 765
Bronco Info: '79 Bronco XLT
iTrader: (0)
Quote:
Originally Posted by Chuck
First off, a very handy tool one of the other guys here linked up the other day ... excellent rpm calculator for various gears, transmissions, tires, and transfer case combinations. It's the quickest and cleanest tool I've seen yet for checking engine speed for different conditions, plus the owner of the site has been very quick to add different transmissions on request.
Is it me or are the HI / LO backwards? The colors on the graph? Says LO is faster than HI...

1979 Bronco Ranger XLT
351M
Dave88LX is offline
post #50 of 330 (permalink) Old 03-16-2006, 12:44 PM
Registered User

Chuck's Avatar

Join Date: Feb 2005
Location: Smithfield, VA
Posts: 1,213
Bronco Info: 91 302/E4OD/3.55, F-150 cab
iTrader: (0)
Quote:
Originally Posted by Dave88LX
Is it me or are the HI / LO backwards? The colors on the graph? Says LO is faster than HI...
I know he does a lot of tweaking on the calculator, he may have flipped colors on something by accident ... I hadn't been paying attention to the range colors, so I hadn't noticed.

Unfamiliar the miles under my heels ...
Structural Engineer / General Steel Geek
A Turn Of The Nut -- Pickwick Fields Lamb -- 87/91 F-150 cab swap -- My Supermotors
Chuck is offline
post #51 of 330 (permalink) Old 03-16-2006, 01:28 PM
Registered User

4Wheelin Rust bucket's Avatar

Join Date: Sep 2004
Location: dirty jersey
Posts: 606
Bronco Info: 1986 xlt 5.0 stock an 1983 xlt 92 mustang 302,6"lift,rear locker,ghetto fab roll cage,cheapo 35's
iTrader: (6)
how would one know what the gear ratio in an axle with no tag or vin code? (9inch from a 78 or 79 ford PU) supposedly the axle has the stock running gears but that could be several, i remember a thread awhile back about counting rotations of the driveshaft whille spinning the tires.....but searched an couldnt find it. am i just gonna have to pull the carrier?

ive had it in 4wd in deep mud with 40's an it never gave me a prob, but i have smaller tires now an im driving on the street more. if it snows i wanna have 4wd an light trail use but dont wanna break anything till i know for sure. im guessing 3.50 an compared to the 3.54 in front i dont think i should have that much of a problem.

i wanna be sure though, Thanks for any help i could get.

The only purple grape bronco with a neon green 9inch around


4Wheelin Rust bucket is offline
post #52 of 330 (permalink) Old 03-16-2006, 06:02 PM
Registered User

Chuck's Avatar

Join Date: Feb 2005
Location: Smithfield, VA
Posts: 1,213
Bronco Info: 91 302/E4OD/3.55, F-150 cab
iTrader: (0)
No problemo. Method differs slightly depending on whether it's open or limited slip, so that's the first thing you check. Chock the front wheels and lift both rears off the ground, but leave it in park or in gear. Try to turn one wheel forward. If the other wheel turns backward easily, it's either open or a very worn out lsd. If it won't turn (or takes at least about 30lb-ft minimum to turn), then it's limited slip.

Now, with that out of the way, here's how you check the ratio for each.

Limited slip: Leave both back wheels off the ground, put transmission or transfer case in neutral. Use chalk or a crayon to mark the driveshaft and a spot on the tire. Rotate the back wheel forward, and count the number of full rotations as w. Have a friend count the number of full rotations of the driveshaft, and call that number d. Your gear ratio is d/w. You can get away with only rotating the wheel a couple of times, but the more rotations you count, the more accurate the results. For instance, I usually prefer about w=10, it's big enough to be accurate but makes for easy math. With my 3.55's, that means the driveshaft turns 35 and 1/2 times -- enough turns that you can actually tell the difference between a 3.50 and 3.55 ratio by whether or not the shaft makes that last half turn. If you only turn the wheel twice, you get 7.1 turns on the driveshaft. Can you really eyeball 0.1 turns accurately? If you counted 7 turns on the driveshaft, you'd get 3.50, but it's still "close enough" if you just what a rough idea of what a vehicle has.

The procedure for an open diff is very similar but just as simple. Put the tranny in neutral, but put the opposite wheel down on the ground. When you turn your wheel, since the other wheel is still, the diff will turn half as many times. This throws a factor of 1/2 into the formula. Again, counting w (wheel revolutions) and d (driveshaft revolutions), your gear ratio = 2*d/w. I usually use 20 turns of the wheel when I want to be accurate with an open diff. For my 3.55's, that means 20 turns on the wheel (with the other wheel on the ground) would give me 35 and 1/2 turns on the driveshaft again.

The cliff's notes:
Count w = number of wheel revolutions, d = number of driveshaft revolutions
LSD: Both wheels in the air, ratio = d/w
Open: One wheel on the ground, ratio = 2*d/w

Unfamiliar the miles under my heels ...
Structural Engineer / General Steel Geek
A Turn Of The Nut -- Pickwick Fields Lamb -- 87/91 F-150 cab swap -- My Supermotors
Chuck is offline
post #53 of 330 (permalink) Old 03-16-2006, 11:35 PM
Registered User

4Wheelin Rust bucket's Avatar

Join Date: Sep 2004
Location: dirty jersey
Posts: 606
Bronco Info: 1986 xlt 5.0 stock an 1983 xlt 92 mustang 302,6"lift,rear locker,ghetto fab roll cage,cheapo 35's
iTrader: (6)
Thanks!!!

The only purple grape bronco with a neon green 9inch around


4Wheelin Rust bucket is offline
post #54 of 330 (permalink) Old 05-17-2006, 05:17 AM
Registered User

Join Date: Jul 2005
Location: Norway
Posts: 140
Bronco Info: 81(89-94) 408"
iTrader: (0)
Quote:
Originally Posted by Chuck
I know he does a lot of tweaking on the calculator, he may have flipped colors on something by accident ... I hadn't been paying attention to the range colors, so I hadn't noticed.
That was a small bug, sorry for the inconvenience.
I really appreciate feedback so I can make this little tool better.
Just let me know if something is off or missing.

Sam Houlder - Norway
~81-89(94) World ManoWar 460" smallblock, AFR225, NOVI2000, JayAllen cam, Bassani/Flowmaster, MegaSquirted, 62# inj
Auburn Pro/Detroit 4.56 . 32x11.5. 4R100/PTCS, STC Fasttrac,

http://www.balsa.no/bil/calcs/gearcalc
Nordic is offline
post #55 of 330 (permalink) Old 07-18-2006, 04:48 AM
Registered User

djdan's Avatar

Join Date: Nov 2004
Location: Indianapolis, IN
Posts: 544
Bronco Info: 1992 EB 5.8 Durabak Black Chuck Norris "Thumbs Up" Edition
iTrader: (4)
Realistically what can I expect to pay to have my bronco regeared from 3.5 to 4.56?

If I had all the parts what would/should the labor cost roughly?

djdan is offline
post #56 of 330 (permalink) Old 07-18-2006, 09:36 AM
Fullsize Member

Join Date: Nov 2003
Location: Tallahassee
Posts: 7,401
Bronco Info: 1990 Bronco XLT 302/AOD ELocker Rear/ custom 8.8. 1986 Bronco XLT. 1981 Bronco Custom
iTrader: (4)
Quote:
Originally Posted by djdan
Realistically what can I expect to pay to have my bronco regeared from 3.5 to 4.56?

If I had all the parts what would/should the labor cost roughly?
If the axles were out, ~$125-225 per axle. If they are in, it could double. This will vary with the part of the country. If you search, you may find info on this since it has been discussed from time to time.

ΜΟΛΩΝ ΛΑβΕ
BlueBronco is offline
post #57 of 330 (permalink) Old 01-16-2007, 11:19 AM
Registered User

Join Date: Sep 2006
Location: Denton
Posts: 168
Bronco Info: 96 Grn XLT 302 6" lift w/ 35" M/T All Terrains w/ Blk Beadlocks Custom Front Bumper
iTrader: (1)
If I currently have stock gears in my 96 bronco dana 44 front 8.8 rear w/ stock gears and I want to chane my gears to 4.56s will i need a new carrier for both axles?
biggrbbronco96 is offline
post #58 of 330 (permalink) Old 01-16-2007, 12:23 PM
Fullsize Member

Join Date: Nov 2003
Location: Tallahassee
Posts: 7,401
Bronco Info: 1990 Bronco XLT 302/AOD ELocker Rear/ custom 8.8. 1986 Bronco XLT. 1981 Bronco Custom
iTrader: (4)
Quote:
Originally Posted by biggrbbronco96 View Post
If I currently have stock gears in my 96 bronco dana 44 front 8.8 rear w/ stock gears and I want to chane my gears to 4.56s will i need a new carrier for both axles?
Just the front.

ΜΟΛΩΝ ΛΑβΕ
BlueBronco is offline
post #59 of 330 (permalink) Old 01-16-2007, 01:23 PM
Registered User

ScottMoore's Avatar

Join Date: Aug 2005
Location: Austin, TX
Posts: 1,265
Bronco Info: 1996 5.8L, 6" CII Lift, 3" Body, 36x14.5x15 Rad. TSL's, 4.56 & Aus Lock, Elect. Fan, & other stuff
iTrader: (0)
But if your 96 has the limited slip in the 8.8 you will need to get an open carrier for it. I got mine out of a junk yard.

-Scott Moore
Arguing online is like winning the special olympics, even if you win your still retarted.

Web Site: http://www.supermotors.net/vehicles/registry/15436
ScottMoore is offline
post #60 of 330 (permalink) Old 01-16-2007, 01:56 PM
Fullsize Member

Join Date: Nov 2003
Location: Tallahassee
Posts: 7,401
Bronco Info: 1990 Bronco XLT 302/AOD ELocker Rear/ custom 8.8. 1986 Bronco XLT. 1981 Bronco Custom
iTrader: (4)
Quote:
Originally Posted by ScottMoore View Post
But if your 96 has the limited slip in the 8.8 you will need to get an open carrier for it. I got mine out of a junk yard.
Why?

ΜΟΛΩΝ ΛΑβΕ
BlueBronco is offline
Reply

  Ford Bronco Forum > Bronco Discussions > Technical Write Ups

Quick Reply
Message:
Options

Register Now



In order to be able to post messages on the Ford Bronco Forum forums, you must first register.
Please enter your desired user name, your email address and other required details in the form below.

User Name:
Password
Please enter a password for your user account. Note that passwords are case-sensitive.

Password:


Confirm Password:
Email Address
Please enter a valid email address for yourself. DO NOT USE Gmail.com accounts. If you only have a Gmail.com email please contact the administrator here

Email Address:
OR

Log-in









Human Verification

In order to verify that you are a human and not a spam bot, please enter the answer into the following box below based on the instructions contained in the graphic.



Thread Tools
Show Printable Version Show Printable Version
Email this Page Email this Page
Display Modes
Linear Mode Linear Mode



Posting Rules
You may not post new threads
You may post replies
You may not post attachments
You may not edit your posts

BB code is On
Smilies are On
[IMG] code is On
HTML code is Off
Trackbacks are On
Pingbacks are On
Refbacks are On


For the best viewing experience please update your browser to Google Chrome
